Input DC 17V ~ 55V to Output DC 9V 6A 36W / 72W waterproof DC to DC converter

5.0 (38)
$4.10 $0.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Discount
  • 3% OFF WITH PURCHASE OVER 10 UNITS
  • 6% OFF WITH PURCHASE OVER 50 UNITS
  • 10% OFF WITH PURCHASE OVER 100 UNITS
  • View More
  • View Less
    Please select the information you want X
  • model:
    17~55V - 9V-6A
Quantity:
Availability: In Stock
  • Description
  Input   DC  17V ~ 55V to Output DC  9V 6A 36W / 72W waterproof  DC to DC converter

Product features
1. It is made of imported chips with high quality and low price.
2. Synchronous rectification technology, the conversion rate is more than 96%, and the calorific value is very low.
3. Automatic braking protection functions such as overvoltage, overcurrent, overtemperature and short circuit, and work normally after the conditions are restored.
4. Epoxy resin potting, waterproof, shockproof, moisture-proof and dust-proof.
5. Small volume and convenient installation.
6. Imported components are adopted with quality assurance. Glue filling and packaging, moisture-proof and waterproof, anti vibration and anti rejection, low heating, stable performance, suitable for long-term work.


  parameter
Module properties Non isolated step-down and voltage stabilizing module
input voltage 17-55V
output voltage 9V
Output current 6A
Output overcurrent protection If the output current is too large, it will automatically over-current limit the output
Output short circuit protection When the output terminal is completely short circuited, the current is automatically limited
Lowest differential pressure 2V
output power Natural cooling 36W / 72W
conversion efficiency Up to 96%
working temperature -40℃~+85℃
Load adjustment rate ±1%
Voltage regulation rate ±0.5%
Dynamic response speed 5% 200uS
